Needled E-Glass Mat (Nonwoven)

Overview
Our mat is the most competitive and the best in quality over the world, which has been proven by lots of customers in many countries. Our E-glass needled mat is a mechanically bonded glass fiber insulation blanket of uniform density supplied in thicknesses of 1/8" , 1/4 ", 1/2", and 1" that offers reliable, superior performance for continuous operating temperatures up to 1000° F (538° C) and excursions to 1200° F (649° C). The E-glass needled mat is manufactured from a well-controlled assortment of long textile glass fibers to assure uniform mechanical bonding with no additional binders, thereby assuring insulation efficiency during extended exposure of elevated temperatures.


Product Characteristics
Low thermal conductivity at temperatures to 1000° F (538° C)
Good drapability conforms to irregular surfaces
0-flame spread, 0-smoke generation
Non-respirable, 9 micron filament diameter
Excellent vibration resistance, will not powder
Excellent sound absorption properties
Non-alkaline (<0.01%)
Low chlorides and fluorides
Will not contribute to metal corrosion
Odorless-will not absorb odors-clean
Will not decay or sustain mold or vermin
Moisture absorption negligible


On initial heat-up past 300° F, there is some outgassing due to a small residual of organics on the glass fiber surface. Adequate ventilation and exhaust should be provided for any enclosed applications during this period.

Applications
- Muffler and exhaust insulation
- Automotive catalytic converter, flooring and front dash insulation
- Removable pads
- Ship turbines
- Marine, industrial and process piping
- Power generating equipment
- Industrial furnaces and ovens
- Filtration
- Supercharger covers

Product Specifications
Thickness Density Max. Width
1/8 inch
(3.18 mm)
7.5-10 lbs/ft³
(120-160 kg/m³)
60 inch
(152.4 cm)
1/4 inch
(6.35 mm)
7-10.5 lbs/ft³
(110-170 kg/m³)
60 inch
(152.4 cm)
1/2 inch
(12.7 mm)
7.5-12.5 lbs/ft³
(120-200 kg/m³)
60 inch
(152.4 cm)
1 inch
(25.4 mm)
9-13.7 lb/ft³
(144-220 kg/m³)
60 inch
(152.4 cm)
